MikroMCP

Execute write operations in order, stopping on first failure. Each step is snapshotted and journaled individually. Non-admin identities need a confirmationToken (same two-step flow as other destructive tools). Undo individual steps via rollback_change with the returned journal IDs.

Run a RouterOS bandwidth test from the router to a remote host running a RouterOS btest server. Returns TX and RX throughput in Mbps. Duration capped at 20 seconds. Saturates the link — not auto-retried.

Fan out a single-router tool to many routers in parallel (up to concurrency), targeted by routerIds or tag. Destructive tools need two-step confirmation: call without confirmationToken to get a fleet token (needs MIKROMCP_CONFIRMATION_SECRET), then re-call with it. Writes snapshot+journal each router for rollback. Returns per-router results with succeeded/failed counts.

Probe a router by fetching system/resource. Returns health status, ROS version, uptime, CPU load, and memory info. Unlike other tools, this never throws — unreachable routers are reported as healthy=false.

Create a binary configuration backup on a MikroTik router. The backup is saved as <name>.backup on the router's filesystem. Supports optional encryption via password and dry-run mode.

Delete a file from the router filesystem by name. Idempotent: returns not_found gracefully if the file does not exist.

Export the router configuration as a RouterOS script. When no file is specified, returns the script text inline. When a file is specified, saves it as <file>.rsc on the router's filesystem. Supports compact mode to show only non-default values.

Send an HTTP/HTTPS request from the router using /tool/fetch. Response body is returned inline (capped at 64 KB with [TRUNCATED] marker). Use outputFile to save to router filesystem instead. Not read-only: POSTs have side effects and outputFile writes to the router.

Read global container configuration: registry URL, RAM high-water mark, and veth interface.

Read DNS resolver configuration: upstream servers, cache size, cache TTL, and whether remote DNS requests are allowed.

Read a text file's contents from a MikroTik router. Only suitable for text files — binary files will return garbled content.

Read and filter the system log from a MikroTik router. Supports filtering by topic, message prefix, and a time window (last N minutes) measured against the router's own clock. Entries with unparseable timestamps are included conservatively.

Retrieve NTP client settings from a MikroTik router.

Get the OpenVPN server configuration on a MikroTik router. Throws NOT_FOUND if the OpenVPN package is not installed.

Retrieve SNMP settings from a MikroTik router.

Read the current date, time, and timezone from a MikroTik router. Focused single-purpose alternative to the clock section in get_system_status.

Retrieve system status information from a MikroTik router including resource usage, identity, license, routerboard details, health sensors, and clock.

Read the current RouterOS package upgrade status and routerboard firmware versions. Shows installed version, latest available version, update channel, and firmware upgrade availability.

List firewall address list entries on a MikroTik router. Supports filtering by list name and address.

List ARP table entries on a MikroTik router.

List BGP sessions on a MikroTik router (RouterOS 7+). Returns state, remote AS, prefix counts, and uptime.

List bridge interfaces and their port members on a MikroTik router.

List certificates on a MikroTik router.

List active connection tracking entries from the router firewall table. Filters are applied client-side. Useful for diagnosing NAT and firewall behavior.

List container environment variable entries, optionally filtered by container name.

List container volume mount definitions with source path, destination path, and mount name.

List RouterOS container instances with status, image, and network information.

List DHCP client configurations on a MikroTik router. Shows which interfaces obtain their IP via DHCP, current status, and assigned address.

List DHCP leases on a MikroTik router with optional filtering by server, status, lease type (dynamic/static), and MAC address. Supports pagination.

List DHCP servers on a MikroTik router.

List static DNS entries on a MikroTik router with optional filtering by name and type.

List files on a MikroTik router filesystem. Supports filtering by name and type.

List firewall rules from the filter or nat table on a MikroTik router. Supports filtering by chain and disabled state, with pagination.

List all interface lists defined on the router.

List network interfaces on a MikroTik router with optional filtering by type and status. Supports pagination and optional traffic counters.

List IP address pools on a MikroTik router. Supports filtering by name and pagination.

List IP services on a MikroTik router (api, api-ssl, ssh, telnet, www, www-ssl, winbox, ftp) with their port numbers and enabled/disabled status.

List IPSec peers on a MikroTik router.

List IPSec policies on a MikroTik router.

List RouterOS logging action targets (system/logging/action) with optional type filter.

List RouterOS logging rules (system/logging) with optional topic substring and action exact-match filtering.

List firewall mangle rules on a MikroTik router in evaluation order. Supports filtering by chain, action, and disabled state.

List discovered neighbors (CDP/LLDP/MNDP) on a MikroTik router.

List Netwatch monitoring entries on a MikroTik router.

List OSPF neighbors on a MikroTik router (RouterOS 7+). Returns neighbor state, interface, DR/BDR, and uptime.

List OpenVPN client interfaces on a MikroTik router. Shows name, remote server, and connection status.

List installed RouterOS packages with version and enabled status.

List PPP profiles including the built-in default and default-encryption profiles.

List PPPoE client interfaces on a MikroTik router. Shows name, parent interface, ISP username, and connection status.

List simple queues on a MikroTik router.

List the routers configured in the registry (routers.yaml): id, host, port, TLS status, tags, ROS version, and which is the default. Read-only reflection of local config — no RouterOS API call, no credentials in the response. Use it to discover valid routerId values and tags for targeting other tools (including bulk_execute).

List static routes on a MikroTik router with optional filtering by active status and dynamic status. Supports pagination.

List policy routing rules on a MikroTik router in evaluation order. Supports filtering by table and disabled state.

List custom routing tables on a MikroTik router.

List RouterOS scheduler entries on a MikroTik router with next-run time, interval, and disabled state.

List RouterOS scripts on a MikroTik router. Supports optional name filter.

List local user groups on a MikroTik router.

List local users on a MikroTik router. Passwords are never returned.

List VRRP instances on a MikroTik router.

List currently connected WiFi clients (stations) with signal strength and transfer rates.

List WiFi/wireless interfaces on a MikroTik router. Uses /interface/wifi on ROS 7.x, /interface/wireless on older versions.

List WireGuard interfaces and their status on a MikroTik router.

List WireGuard peers with last handshake time and transfer statistics.

Add or remove a firewall address list entry. Idempotent by list name + address. Supports dry-run mode.

Create or remove a bridge interface on a MikroTik router. Idempotent: create returns already_exists if bridge with same name exists.

Add or remove an interface from a bridge on a MikroTik router. Idempotent: add returns already_exists if the port assignment already exists.

Remove, trust, or untrust a certificate. Idempotent: trust/untrust return early if already in the target state.

Create, start, stop, or remove a RouterOS container. create needs a pre-configured veth interface; start/stop are no-ops when already in the target state; remove throws NOT_FOUND when absent. Supports dry-run.

Update global container settings. Idempotent: returns no_change if nothing differs.

Add or remove a container environment variable. Idempotent by name+key. add returns already_exists if the entry exists with the same value; throws CONFLICT if the value differs.

Add or remove a container volume mount. Idempotent by name: add returns already_exists if the mount exists with matching src/dst; throws CONFLICT if name exists with different paths.

Add, remove, enable, or disable a DHCP client on an interface. Idempotent by interface name: add returns already_exists if a DHCP client is already configured on the same interface.

Convert a dynamic DHCP lease to static (make-static) or remove a lease. Idempotent by MAC address.

Add, remove, enable, or disable a DHCP server. Idempotent by name: add returns already_exists if a server with the same name, interface, and address pool already exists.

Add or remove a static DNS entry. Idempotent by name+type: add returns already_exists if the same record already exists.

Update DNS resolver settings (upstream servers, cache size, cache TTL, allow-remote-requests). Idempotent: returns no_change if nothing differs.

Add, remove, disable, or enable a firewall rule on a MikroTik router. Uses comment as idempotency key for deduplication and identification. Supports dry-run mode.

Add or remove an interface list. Idempotent by name. Removing a list that has members is blocked by RouterOS — the error is surfaced as-is.

Add or remove an interface from an interface list. Idempotent by list+interface composite key. add returns already_exists if the membership exists. remove returns not_found gracefully.

Add, update, or remove an IP address on a MikroTik router interface. Performs idempotency checks for add operations and supports dry-run mode for all actions.

Add or remove an IP address pool. Idempotent by name: add returns already_exists if a pool with the same name and ranges already exists.

Enable or disable a RouterOS IP service (api, api-ssl, ssh, telnet, www, www-ssl, winbox, ftp). Port number changes are intentionally not supported to prevent accidental lockout.

Add, remove, enable, or disable an IPSec peer. Idempotent by name: add returns already_exists if a peer with the same name and address already exists.

Add, remove, enable, or disable an IPSec policy. Idempotent by composite key (srcAddress + dstAddress + tunnel).

Add or remove a RouterOS logging action target. Idempotent by name. add throws VALIDATION if type is missing; returns already_exists if name found. remove returns not_found gracefully. Supports dry-run.

Add, remove, enable, or disable a RouterOS logging rule. Idempotent by topics+logAction (add → already_exists on match; remove → not_found handled gracefully; enable/disable throw NOT_FOUND when absent). Supports dry-run.

Add, remove, enable, or disable a firewall mangle rule. Uses comment as idempotency key. Supports dry-run mode.

Add, remove, enable, or disable a Netwatch monitoring entry. Idempotent by host+port: add returns already_exists if an entry with the same host and port already exists.

Update NTP client settings on a MikroTik router. Idempotent: returns already_set if no changes are needed.

Add, update, or remove an OpenVPN client interface. Idempotent by name (already_exists on matching name+connectTo; CONFLICT on differing connectTo; no_change when an update differs in nothing). Password is always written when provided since RouterOS does not return it on GET.

Enable, disable, or configure the OpenVPN server (a per-router singleton). Throws NOT_FOUND if the OpenVPN package is not installed. The set action requires at least one configuration field.

Enable or disable a RouterOS package. Changes take effect only after a router reboot — use the reboot tool to apply. Idempotent: no-op if already in the target state.

Add, update, or remove a PPP profile. Idempotent by name. update returns no_change when requested values match. Built-in profiles (default, default-encryption) cannot be removed — RouterOS blocks this and the error is surfaced.

Add, update, or remove a PPPoE client interface. Idempotent by name (already_exists on matching name+interface+user; CONFLICT on differing config; no_change when an update differs in nothing). Password is always written when provided since RouterOS does not return it on GET.

Add, remove, enable, or disable a simple queue. Idempotent by name: add returns already_exists if a queue with the same name and target already exists.

Add or remove a static route on a MikroTik router. Performs idempotency checks for add operations and supports dry-run mode for all actions.

Add, remove, enable, or disable a policy routing rule. Idempotent by srcAddress+dstAddress+interface+table composite key. Supports dry-run mode.

Create or remove a custom routing table. Idempotent by table name. Supports dry-run mode.

Add, update, remove, enable, or disable a RouterOS scheduler entry. Idempotent by name. add throws CONFLICT if name exists; update throws NOT_FOUND if it does not. Supports dry-run.

Add, update, or remove a RouterOS script. Idempotent by name. add throws CONFLICT if the name already exists; update throws NOT_FOUND if it does not. Supports dry-run.

Trigger a RouterOS package update check or install. 'check' queries the update server for new packages. 'install' downloads and applies the update — the router will reboot automatically. Supports dry-run.

Add, remove, enable, disable, or set the password for a local RouterOS user. Idempotent by name: add returns already_exists if a user with the same name and group already exists.

Add, update, or remove a local RouterOS user group. Idempotent by name: add returns already_exists if a group with the same name and policy already exists.

Add, remove, enable, or disable a VLAN interface. Idempotent by name: add returns already_exists when a VLAN with matching name, vlan-id, and parent interface exists. Supports dry-run mode.

Add, remove, enable, or disable a VRRP instance. Idempotent by name: add returns already_exists if an instance with the same name, interface, and VRID already exists.

Enable, disable, or update SSID settings on a WiFi interface. At least one of disabled or ssid must be provided.

Add, remove, enable, or disable a WireGuard interface. Idempotent by name. RouterOS generates the private key on create — it is never passed in. The public key is returned after creation.

Add or remove a WireGuard peer. Idempotent by public key: add returns already_exists if a peer with the same public key already exists on the interface.

Send ICMP echo requests from the router to a target address. Returns per-packet RTT and summary statistics. 100% packet loss is a valid result, not an error.

Preview a sequence of write operations: each step runs with dryRun=true against live state, returning affected paths and the predicted action per step. Use apply_plan to execute the same steps for real.

Trigger a controlled router reboot with an optional delay. Supports dry-run. Use this tool instead of run_command for reboots — run_command's deny list blocks /system reboot*.

Restore RouterOS state to before a write, identified by its journal ID: reads the before-snapshot, diffs against live state, and applies the reverse. Use dryRun=true to preview the restore plan. Requires MIKROMCP_DATA_DIR (defaults to data/).

Execute an arbitrary RouterOS console command via SSH. Guarded by an allow/deny policy (built-in deny list blocks destructive commands; tighten via cmdAllow in routers.yaml or MIKROMCP_CMD_ALLOW). Prefer dedicated tools (reboot, etc.) where available. Output capped at 4000 characters.

Execute a named RouterOS script. Fire-and-forget — the script runs asynchronously and its output is written to the router system log. Use get_log after calling this tool to see results.

Set the system date, time, and/or timezone on a MikroTik router. Idempotent: returns already_set if the values already match. Supports dry-run.

Capture a real-time traffic snapshot on a router interface. The tool call blocks for the duration (seconds) and returns top flows by bytes. readOnlyHint true — auto-retry enabled.

Trace the network path from the router to a target address. Returns an ordered hop list with RTT per hop. Timeouts and partial results are valid responses.

Upload a text file to a router, overwriting any existing file of the same name. Prefers SFTP (encrypted, over SSH) and falls back to plaintext FTP if SFTP is unavailable. Requires SSH (or FTP) access for the router user. Dry-run tests connectivity only.
