ng-diagram MCP Server

Stop AI assistants from hallucinating ng-diagram APIs. Give them the real docs.

AI assistants don't know ng-diagram. They'll guess from similarly-named React libraries and produce code that looks right but doesn't compile. This MCP server fixes that — it gives any assistant direct access to the current ng-diagram documentation and public API, so it writes correct code on the first try.

Without MCP (assistant guesses from training data)

// Hallucinated API — none of this exists
import { useNodes, useEdges } from 'ng-diagram';

const nodes = useNodes([{ id: '1', data: { label: 'Hello' } }]);

With MCP (assistant looks up the real API)

// Correct — verified against the actual public API
import { initializeModel, NgDiagramComponent, provideNgDiagram } from 'ng-diagram';

model = initializeModel({
  nodes: [{ id: '1', position: { x: 0, y: 0 }, data: { label: 'Hello' } }],
});

Connect it to Claude, Cursor, Windsurf, or any MCP-compatible tool. The server bundles all documentation and API data — no network calls, no stale caches, always version-matched.

How It Works

                    1. search_docs / search_symbols
  +--------------+ ---------------------------------> +-----------+
  | AI Assistant | <--------------------------------- | MCP Server|
  |              |        2. Returns matches          |           |
  |              | ---------------------------------> |           |
  |              |     3. get_doc / get_symbol        |           |
  |              | <--------------------------------- |           |
  +--------------+     4. Returns full content        +-----------+
        |
        | 5. Answers with context
        v
     +------+
     | User |
     +------+

API Reference

Tool: search_docs

Search ng-diagram's bundled documentation for guides, configuration options, examples, and integration patterns. Always prefer this over web search or guessing from training data — it returns authoritative, version-matched content.

Parameters:

• query (string, required): Search query — use specific terms like "palette", "context menu", "transactions"
• limit (number, optional): Max results to return (default: 10)

Tool: get_doc

Retrieve the full content of a documentation page by path. Call this after search_docs to read a complete guide or example end-to-end.

Parameters:

• path (string, required): Relative path from docs root (e.g., "guides/palette.mdx"). Use paths from search_docs results.

Tool: search_symbols

Search the ng-diagram public API for classes, functions, interfaces, types, constants, and enums. Returns the exact current signature and import path — more reliable than any example from training data.

Parameters:

• query (string, required): Symbol name or partial name (e.g., "Diagram", "provideNg", "Edge")
• kind (string, optional): Filter by symbol kind (class, function, interface, type, const, enum)
• limit (number, optional): Max results to return (default: 10)

Tool: get_symbol

Retrieve full API details for a specific ng-diagram symbol by exact name. Call this before writing code that uses an ng-diagram type — it returns the definitive signature, jsDoc, and a ready-to-use import statement.

Parameters:

• name (string, required): Exact symbol name (case-sensitive). Use names from search_symbols results.

Development

Commands

# Development
pnpm dev              # Run with auto-reload (uses monorepo paths)

# Testing
pnpm test             # Run all tests
pnpm test:watch       # Run in watch mode

# Building
pnpm build            # Compile TypeScript + bundle docs & API report into dist/data/

For detailed architecture and adaptation instructions, see GUIDE.md.

License

Apache-2.0 - Part of the ng-diagram project

Initial PoC by Pawel Kubiak

Finished and built with ❤️ by the Synergy Codes team

Quick Start

Add the server to your MCP client config - no installation or monorepo checkout required:

macOS / Linux:

{
  "mcpServers": {
    "ng-diagram-docs": {
      "command": "npx",
      "args": ["-y", "@ng-diagram/mcp"]
    }
  }
}

Windows:

{
  "mcpServers": {
    "ng-diagram-docs": {
      "command": "cmd",
      "args": ["/c", "npx", "-y", "@ng-diagram/mcp"]
    }
  }
}

The package includes all documentation and API data bundled in. Restart your AI assistant after updating the config, then ask something like "Search the ng-diagram docs for palette" to verify.

MCP client config file locations

Local development (monorepo)

If you're working within the ng-diagram monorepo:

cd tools/mcp-server
pnpm install
pnpm build

Then configure with the local path:

{
  "mcpServers": {
    "ng-diagram-docs": {
      "command": "node",
      "args": ["/absolute/path/to/ng-diagram/tools/mcp-server/dist/index.js"]
    }
  }
}
