Union - Unity MCP Server

★ 33

from nurture-tech

An MCP server for managing and interacting with Unity projects.

🔥🔥🔥✓ VerifiedFreeAdvanced setup

#automation #devops #git

[!IMPORTANT] Union is deprecated. Use Unity's official MCP server.

Union ♾️ - The Unity MCP Server

A Model Context Protocol server for Unity

Doki Delivery Airship

Key Features

🖼️ Multimodal Vision: Your agent can see what you see. It can view the scene, look through any camera, watch play mode, and inspect asset thumbnails.
🔎 Powerful Search: Go beyond the project panel with simultaneous search across the hierarchy and project assets.
✔️ Superior Code Analysis: Leverage Unity's own compiler for code analysis that is more accurate than your agent's linter.
⏩ Quick Start: Get running in seconds with a single mcp.json configuration file.
🛠️ Extensible: Add your own project-specific tools with minimal boilerplate.
📅 Always Current: Kept up-to-date with the latest MCP protocol version — currently 2025-06-18 via the Official MCP C# SDK.

Compatibility

Name	Compatible	Notes
Models
GPT-4.1	✅
Claude 4 Sonnet	✅
Claude 4 Opus	✅
Gemini 2.5 Pro	✅
Gemini 2.5 Flash	✅
o3	✅	No image understanding
o4-mini	✅
Unity Versions
Unity 6000.0.x	✅	Higher versions should be fine. Lower versions may work but untested.
Agents
Cursor	✅
Rider AI	✅
Claude Desktop	✅
Claude Code	✅	Terminal requires Screen & System Audio Recording permissions on Mac
Operating Systems
Windows	✅
Mac	✅
Ubuntu	❔	Untested

About the Tools

Meet your Unity AI toolbox.

Tool	Description
Assets
`get_asset_contents`	Get the full contents of an asset or sub-asset.
`copy_asset`	Copy an asset to a new path.
`import_asset`	Import an asset from the filesystem into Unity.
`get_asset_importer`	Get the importer settings for an asset.
Prefabs
`open_prefab`	Open a Unity prefab in isolation mode so that it can be edited.
Scenes
`open_scene`	Open a scene
`close_scene`	Close an open scene
`save_scene`	Save the current scene. If the scene is not dirty, this will do nothing.
`get_game_object`	Get the details of a game object in a loaded scene or prefab by its hierarchy path.
`test_active_scene`	Test the active scene by entering play mode and running for a given number of seconds.
Scripting
`create_script`	Create or replace a C# code file at the given path. This also checks to make sure the script compiles.
`execute_code`	Execute code inside the Unity editor.
`get_type_info`	Get public fields and methods on a Unity fully qualified type name, including the assembly.
Search
`search`	Search project assets and scene objects.
Editor State
`get_state`	Get the state of the Unity Editor.
`get_selection`	Get the objects the user has currently selected in the editor.
Vision
`focus_game_object`	Focus on a game object in the scene view.
`screenshot`	Retrieve a preview of what is focused in the scene view.

Adding Project-Specific Tools

Union uses the official C# MCP SDK.

Create a static class to hold your tools. Add the [McpServerToolType] annotation to the class.
Declare static methods to implement each tool. Add the [McpServerTool] annotation to each method.
Reference the Services directory for examples.
You will likely need to quit unity and restart your agent in order for it to see the new tools.

Setup

1. Install node.js

2. Configure `mcp.json`

{
  "mcpServers": {
    "unity": {
      "command": "npx",
      "args": ["-y", "@nurture-tech/unity-mcp-runner", "-unityPath", "<path to unity editor>", "-projectPath", "<path to unity project>"]
    }
  }
}

This will automatically install the is.nurture.mcp package in your unity project. Feel free to commit those changes to source control.

Usage Tips

Here are some tips to get the most out of Union:

🚀 Launch through your agent: Always launch Unity through your AI agent's MCP integration. Launching Unity from the Hub will prevent the MCP server from connecting.
📂 Per-project setup: If your agent supports it, configure the MCP server in your per-project settings. This allows you to seamlessly switch between Unity projects.

⚙️ Command-line arguments: You can pass additional arguments to Unity for advanced scenarios like running in -batchmode or -nographics for CI/CD pipelines. Add a -- separator before the Unity-specific arguments:

{
  "mcpServers": {
    "unity": {
      "command": "npx",
      "args": [
        "-y",
        "@nurture-tech/unity-mcp-runner"
        "-unityPath",
        "<path to unity editor>",
        "-projectPath",
        ".",
        "--",
        "-batchmode",
        "-nographics"
      ]
    }
  }
}

⚠️ Important: Do not use the -logFile command-line argument. The MCP server relies on Unity's standard output for communication.
🖥️ Split screen for vision: For tools like screenshot, ensure the Unity editor is visible on your screen otherwise it will end up screenshotting the foreground window.
